ROOFING SHINGLES

Your home is your sanctuary. It's the place where you want to feel the most comfortable, safe, protected. But no matter how much you love your house, it seems that the work is never completely done. And if purchasing a new roof is on your to-do list, it may seem like a daunting task—especially if your roof is already damaged or leaking. Since the roof plays such an important role in protecting you and your family from the elements, you realize that you can't let the damage get out of hand.

Shingles are specially formulated to provide greater contrast and dimension to any roof. They give a truly unique and dramatic effect like no other with bold colors, lively contrast and complementing shadow lines for dimension.

Due to the presence of patented technology, a unique triple layer occurs when the fabric overlays the common bond of the shingle laminate layers that offer excellent fastener holding power.

These feature a tough, woven engineered reinforcing fabric to deliver consistent fastening. Specially formulated, wide adhesive bands help keep shingle layers laminated strong.

KEY APPLICATION AREAS

• Sloped roofing (wooden or RCC)

• Designer/ Architectural roofing

• Residential/ hospitality sector

SMART BENEFITS:

• Breakthrough Design:

Featuring a tough, woven engineered reinforcing fabric to deliver consistent fastening during installation.

• Triple Layer Protection™:

A unique "triple layer" of reinforcement occurs when the fabric overlays the common bond of the shingle laminate layers that offer excellent fastener holding power.

• Superior Adhesion:

Our enhanced sealant grips tightly to the engineered fabric nailing strip on the shingle below.

• Excellent Adhesive Power:

Specially formulated, wide adhesive bands help keep shingle layers laminated together.

• Exceptional Wind Resistance:

The industry's first asphalt roofing shingle engineered to deliver 130-MPH* wind warranty performance with only 4 nails. 33% fewer nails are required for maximum warranty

KEY TECHNICAL SPECIFICATIONS / VARIANTS:

• Nominal size : 13 1⁄4" x 39 3⁄8"

• (Algae Resistant) Shingles: .

1. Nominal Size: 13-1/4 in (337 mm) by 39-3/8 in (1000 mm).

2. Exposure: 5-5/8 in (143 mm).

3. Shingles per Square: 64.

4. Bundles per Square: 3 bundles of 20 or 22 shingles.

5. Coverage per Square: 98.4 sq ft (9.1 sq m).

6. Color: As selected from manufacturer's full range.

7. Standards/Qualifications: ASTM D228, ASTM D3018 (Type 1), ASTM D3161 (Class F Wind Resistance), ASTM D3462, ASTM D7158 (Class H Wind Resistance), ASTM E108/UL 790 (Class A Fire Resistance), CSA A123.5, Florida Product Approval (FL10674), Miami-Dade County Product Approval (12-0309.01), ICC-ES AC438, and UL ER2453-01.
